Cable lug surface thermocouple, Type K
- Temperature range: -100 °C to +350 °C continuous
- Wire type: Teflon with CU shielding, Tmax: +200 °C continuous
Description
This surface thermocouple is made solely for screwing on. The placement of the measurement point the surface to be screwed-on guarantees optimum temperature detection. We kept the most common thread sizes in mind for fastening.
Technical data
- Thermocouple pairing: Type K
- Limiting deviation:Cl. 1 as per DIN EN 60584-1: 2014-07
- Measurement point:In the cable lug near the attachment point
- Housing: Cu tinned
- Fastening screw: M4 / M5 / M6 / M8
- Conductor:Teflon with CU shielding
- Conductor: Strand, 2x 0.22 mm²
- Wire length: 500–5,000 mm
- Connection: Selection
Discount on large quantities on request
