Silicone | Type J | AWG 24F

Technical data:

Thermocouple combination: Fe-CuNi Type „J”
Limiting deviation: Class 1, DIN IEC 584 Part 2, +/- 1.5 °C or 0.004 x | t |
Stranded conductor: stranded, AWG 24F, 2 x 0.22 mm² (7 x 0.2 mm)
Conductor insulation: silicon
Conductor guide: stranded
Outer sheathing: silicon
Operating temperature: -50 °C to +180 °C
Outer dimension: approx. 3.5 mm round
Sheathing colour: black
Core colour: + = black, – = white

Sales only to companies, traders and institutions.

We manufacture according to individual configuration within 1-2 weeks and according to your requirements. Our probes and sensors are completely produced within a very short time at our location in Germany.

Description
Additional information

Description

Thermowire
Si/SiTW-24F-JJ-IEC

Technical data:

Thermocouple combination: Fe-CuNi, Type „JX”
Limiting deviation: Class 1, as per DIN EN IEC 60584-3:2022-02
Stranded conductor: stranded, AWG 24F, 2 x 0.22 mm² (7 x 0.2 mm)
Conductor insulation: silicon
Conductor guide: stranded
Outer sheathing: silicon
Operating temperature: -50 °C to +180 °C
Outer dimension: approx. 3.3 mm round
Sheathing colour: black
Core colour: + = black, – = white

Packaging

individual lengths possible
coiled as ring up to 25m
more then 25m on a plastic coil
delivery as one piece, if not diffrently declared

Discount on large quantities on request.

Additional information

Weight	0,18 kg

Your advantages with us for over 30 years

Entire production made in Germany (100% handmade)
German specialists (Employees have mostly been with the family business since it was founded)
High quality and maximum of durability (high quality materials, better and experienced manufacturing)
Custom-made production according to specific configuration within 1-2 weeks and according to your requirements
Buy sensors & probes online including configuration + further scale of discounts on request

SKU: 438 Categories: Wires and cables, Thermowires, Type "J", Other, Compensating wires, Type "J", Other
