Length 25 m
Technical data:
- Thermocouple combination: Fe-CuNi Type “J”
- Limiting deviation: Class 1, DIN IEC 584 Part 2, +/- 1.5 °C or 0.004 x | t |
- Conductor: Strand, AWG 24F, 2 x 0.22 mm² (7 x 0.2 mm)
- Conductor insulation: PTFE Teflon
- Conductor guide: open strands
- Operating temperature: -190 °C to +260 °C
- Outer dimension: approx. 2.3 mm round
- Core colour: + = black, – = white
